SPD4027Z is a power divider which has high power handling capability up to 1W and wide band operation 18 to 27GHz.
SPD4027Z Power Divider
Key Features
High power handling capability up to 1W
Wide band operation
High isolation within operational band
Low Insertion loss
Stable performance over temperature
LMDS multi-carrier operation
High peak to average handling capability
All specifications can be modified upon request
| Frequency Range | 18 to 27 GHz |
| Insertion Loss | 14.5 dB |
| Isolation (typ.) | 10.5 dB |
| Input VSWR (typ.) | 1.3:1 |
| Output VSWR (typ.) | 1.8:1 |
| Amplitude Imbalance (typ.) | ±0.3 dB |
| Phase Imbalance | ±3 deg |
| Power Rating | Forward Power: 1W Peak Power: 10W (10% Duty Cycle, 1 us Pulse Width) |
| Impedance | 50Ω |
| Weight | 1.6 Max. ounces |
| Input / Output Connectors | SMA-Female |
| Material | Aluminum |
| Finish | Nickel Plated |
| Operational Temperature | -40ºC~+85ºC |
| Storage Temperature | -50ºC~+105ºC |
| Altitude | 30,000 ft. (Epoxy Sealed Controlled environment) 60,000 ft. 1.0psi min (Hermetically Sealed Un-controlled environment) (Optional). |
| Vibration | 25g RMS(15 degrees 2KHz) endurance, 1 hour per axis |
| Humidity | 100% RH at 35c, 95%RH at 40ºc |
| Shock | 20G for 11msec half sine wave,3 axis both directions. |
Main Module
| Module No. | Item | Description |
| SPD4027Z | Power Divider | Frequency range: 18 to 27 GHz; Insertion Loss: 14.5 dB; Isolation: 10.5 dB. |
