SPA-0P6-6 Series Broadband SSPA

Overview Specifications Ordering Resources

Saluki SPA-0P6-6 series is a solid-state RF power amplifier with an output frequency of 0.6GHz to 6GHz and an output power of a maximum of 500W. Its design is based on the most advanced GaN technology in the industry, and its power output is efficient and reliable. The product has functions such as temperature and current detection, alarm protection and so on.

The broadband solid state power amplifier is mainly used for testing and measuring instruments, Communication or interference, aviation control and other fields.

Key Features

Multi-octave broadband performance

High output power

Wide dynamic range

High-efficiency GaN technology

Low power consumption

Low spurious signal

Forward & reverse power monitoring

Extremely load-resistant

Over voltage, over temperature, over current protection

CE, RoHS certification

Frequency Range	0.6GHz – 6GHz
Output Power	20W / 60W / 160W / 200W / 300W / 500W
Gain	43dB / 47dB / 50dB / 56dB / 57dB (min.)
Input VSWR	1.5:1 / 2:1 (typ.)
Impedance	50 ohm
Communication Interface	RS485, LAN
Power Supply	AC 220V±10%, 50/60Hz
Cooling Type	Air cooling
Operating Temperature	0 to 50℃
	(Note: see more technical specifications in the ‘Resource’ – ‘Datasheet’)

Main Machine

Module No.	Item	Description
SPA-0P6-6-20	Solid State Power Amplifier	0.6GHz to 6GHz, output power 20W
SPA-0P6-6-60	Solid State Power Amplifier	0.6GHz to 6GHz, output power 60W
SPA-0P6-6-160	Solid State Power Amplifier	0.6GHz to 6GHz, output power 160W
SPA-0P6-6-200	Solid State Power Amplifier	0.6GHz to 6GHz, output power 200W
SPA-0P6-6-300	Solid State Power Amplifier	0.6GHz to 6GHz, output power 300W
SPA-0P6-6-500	Solid State Power Amplifier	0.6GHz to 6GHz, output power 500W

Options

Module No.	Item
001	Overdrive protection
002	GPIB interface
003	LAN interface	(refer to the datasheet for specific options）
