SLNA0P5406Y Low Noise Amplifier

SLNA0P5406Y is a wideband low noise RF coaxial amplifier covering frequency from 0.5GHz to 40GHz. The amplifier offers 45dB typical high gain, 4.0dB typical noise figure and +22dBm typical output power of P1dB.

Saluki’s RF amplifier brings compact and reliable gain block performance to MW&RF designers, wireless infrastructure, and systems integrators.



Unit Price: US$ 6,499

Click here to purchase online !



(Note: send email to sales@salukitec.com for more modules)

Key Features

Ultra wide band operation 0.5GHz - 40GHz

Gain: 45dB typical

Noise figure: 4.0dB typical

P1dB output power: +22dBm typical

Supply voltage: +12V @ 550mA

50 ohm matched input / output

Frequency Range

0.5 GHz to 40 GHz

Gain

45 dB (typ.)

Gain Flatness

± 4.0 dB

Noise Figure

4.0 dB (typ.)

Input VSWR

1.6:1 (typ.)

Output VSWR

1.6:1 (typ.)

Output 1dB Compression Point (P1dB)

22 dBm (typ.)

Saturated Output Power (Psat)

23 dBm (typ.)

Output Third Order Intercept (OIP3)

27 dBm (typ.)

Supply Current

+12V @ 550mA (typ.)

Isolation S12

-60 dB

Connector

2.92mm (female)

Finish

Gold plated

Material

Aluminum

Size

32 (L) × 45 (W) × 13.5 (H) mm

Weight

Maximum 3.88 ounces

(Note: see more detail information in the ‘Resource’ – ‘Datasheet’)

Main Module

Module No. Item Description
SLNA0P5406Y Low Noise Amplifier 0.5 to 40GHz, Gain 45dB, 2.92mm (female)
