SFED-02 series adopts 3.5-inch HD LCD screen, which can magnify the image of the fiber end face by 400 times and supports the real time video recording function. The detector is small in size and easy to carry. The display has a built-in lithium battery, which can work continuously for more than 20 hours after a single charge.
SFED-02 Optical Fiber Inspection Probe
Key Features
400 times magnification
3.5 inch HD LCD display
Support to create the real time video
1/3 inch sensor, 300,000 effective pixels
4000mAh capacity Li-on battery, 20 hours standby
Small size, rotary metal bracket, convenient and stable
Compatible for UPC (FC/SC/ST/LC) connector and APC (SC) connector
| 1. Detection Probe | |
| Magnification | 400X |
| Resolution | Surpass 1.0µm |
| Visual Range | 0.316 × 0.285 µm |
| Dimension | 139 × 48 × 48 mm |
| Image Sensor | 1/3 480 |
| Weight | 0.11kg |
| 2. LCD Display | |
| Image | • Image size: 22mm • Pixels: 307200 |
| Video | • Frequency: 25FPS • LCD screen: 960 × 240 LCD • Video output mode: NTSC/PAL • Playback format: avi |
| User Interface | • Compatible memory card: TF • Capacity: 8GB • USB: 1.1/2.0 • Hard disk format: FAT32 |
| Battery | 4000mAh lithium battery |
| Dimension | 150 × 26 × 93 mm |
| Weight | 0.3kg |
Main Machine
| Module No. | Item | Description |
| SFED-02 | Optical Fiber Inspection Probe | Including FC/ST/SC/LC male UPC, SC/LC female UPC adapter |
Options
| Module No. | Item | Description |
| SFED-02-1 | APC SC adapter | SC female/male APC |
