1465 series microwave signal generators, with the frequency range of 100kHz – 67GHz, is provided with high purity spectrum and high output power. It can meet the high-end requirements of electromagnetic signal tests. 1465 series owns the functions of high-precision analog sweep and high-performance analog and pulse modulation, with maximum bandwidth of internally modulated signal generator up to 10MHz, various signal waveforms, the minimum pulse width of 20ns and flexible pulse trains, which can meet the test requirements of analog and pulse modulations. A 10.1 inch display screen as well as a number of independent operation styles, such as buttons, mouse and touch screens are equipped so as to improve user experience and test efficiency.
1465 series can generate high-quality continuous-wave or modulated signals, which are not only ideal local oscillation source and clock source, but also high-performance analog simulation signal source. They are mainly used in the radar performance evaluation, high-performance receiver test and components parameter test etc., and applicable to aviation, aerospace, radar, communication and navigation equipment etc.
1465 Series Signal Generator
Key Features
High purity spectrum
Broadband and high-power output
High stability frequency and power output
Convenient touch screen control
Complete frequency band serialization
High-precision analog sweep
Super-high power dynamic range
Excellent analog modulation
High-performance pulse modulation
Multiple control and function extension interfaces
| Frequency Range | 1465C: 100 kHz to 10 GHz, 1465D: 100 kHz to 20 GHz, 1465F: 100 kHz to 40 GHz, 1465H: 100 kHz to 50 GHz, 1465L: 100 kHz to 67 GHz (max. frequency 70 GHz) |
| Frequency Resolution | 0.001 Hz |
| Frequency Switching Time | <20ms (typ.) |
| Time Base Aging Rate | ±5×10-10/day(after continuous switch-on for 30 days) (typ.) |
| Reference Output | • Frequency: 10MHz • Power: >+4dBm, to 50Ω |
| Reference Input | • Frequency: 1-50 MHz, 1Hz step • Power: -5dBm to +10dBm, 50Ω impedance |
| Sweep Mode | Step sweep, list sweep, analog sweep, power sweep |
| High Precision Analog Sweep (Option H03) | Max. sweep speed: • 100kHz ≤ f ≤ 500MHz: 25MHz/ms • 500MHz < f ≤ 1GHz: 50MHz/ms • 1GHz < f ≤ 2GHz: 100MHz/ms • 2GHz < f ≤ 3.2GHz: 200MHz/ms • 3.2GHz < f : 400MHz/ms Sweep accuracy: ±0.05% Sweep width (for 100ms, within the maximum width of 100ms as specified) |
| Minimum Output Power | Standard: • 1465C/D/F: -20 dBm • 1465D + option H06: -10 dBm • 1465H/L: -20 dBm Option H01: • 1465C/D/F: -110 dBm (-135 dBm configurable) • 1465D + option H06: -90 dBm (-125 dBm configurable) • 1465H/L: -90 dBm (-110 dBm configurable) |
| Maximum Output Power (Standard) | 1465C/D: • 100kHz ≤ f ≤ 20GHz: 15 dBm 1465D + option H06: • 10MHz ≤ f ≤ 20GHz: 28 dBm 1465F: • 100kHz ≤ f ≤ 40GHz: 12 dBm 1465H/L: • 100kHz ≤ f ≤ 67GHz: 5 dBm |
| Maximum Output Power (Option H01 Programmable Step Attenuator) | 1465C/D: • 100kHz ≤ f ≤ 20GHz: 15 dBm 1465D + option H06: • 10MHz ≤ f ≤ 20GHz: 27 dBm 1465F: • 100kHz ≤ f ≤ 40GHz: 12 dBm 1465H/L: • 100kHz ≤ f ≤ 30GHz: 5 dBm • 30GHz ≤ f ≤ 67GHz: 4 dBm |
| Maximum Output Power (Option H05 High-power Output) | 1465C/D: • 100kHz ≤ f ≤ 20GHz: 20 dBm 1465F: • 100kHz ≤ f ≤ 9GHz: 20 dBm • 9GHz ≤ f ≤ 40GHz: 17 dBm 1465H/L: • 100kHz ≤ f ≤ 15GHz: 17 dBm • 15GHz ≤ f ≤ 30GHz: 13 dBm • 30GHz ≤ f ≤ 67GHz: 8 dBm |
| Maximum Output Power (Option H05 + H01A/B) | 1465C/D: • 100kHz ≤ f ≤ 20GHz: 20 dBm 1465F: • 100kHz ≤ f ≤ 9GHz: 20 dBm • 9GHz ≤ f ≤ 40GHz: 17 dBm 1465H/L: • 100kHz ≤ f ≤ 15GHz: 17 dBm • 15GHz ≤ f ≤ 30GHz: 13 dBm • 30GHz ≤ f ≤ 67GHz: 8 dBm |
| Power Resolution | 0.01 dB |
| Power Temperature Stability | 0.02 dB/ºC (typical) |
| VSWR | • 100kHz ≤ f ≤ 20GHz: <1.6 • 20GHz < f ≤ 40GHz: <1.8 • 40GHz < f ≤ 67GHz: <2.0 |
| Harmonic Wave (Standard) | • 100kHz ≤ f ≤ 10MHz: < -25dBc • 10MHz < f ≤ 2GHz: < -30dBc • 2GHz ＜ f ≤ 6GHz: < -30dBc (S1465B) • 2GHz ＜ f ≤ 20GHz: < -55dBc • 20GHz ＜ f ≤ 40GHz: < -50dBc (typ.) (at +10dBm or Max. specified output power, whichever is lower) |
| Harmonic Wave (Option H06 Enhanced High-power) | • 10MHz < f ≤ 2GHz: < -25dBc • 2GHz < f ≤ 9GHz: < -35dBc • 9GHz < f ≤ 14GHz: < -27dBc • 14GHz < f ≤ 20GHz: < -30Bc (at +10dBm or Max. specified output power, whichever is lower) |
| Sub-harmonic Wave (Standard) | • 100kHz ≤ f ≤ 10GHz: None • 10GHz < f ≤ 20GHz: < -60dBc • 20GHz < f ≤ 67GHz: < -50dBc (at +10dBm or Max. specified output power, whichever is lower) |
| Non-harmonic Wave (Standard) | • 100kHz ≤ f ≤ 250MHz: < -58dBc • 250MHz < f ≤ 3.2GHz: < -74dBc • 3.2GHz ＜ f ≤ 10GHz: < -62dBc • 10GHz ＜ f ≤ 20GHz: < -56dBc • 20GHz ＜ f ≤ 40GHz: < -50dBc • 40GHz ＜ f ≤ 67GHz: < -44dBc (At 0dBm, beyond 3kHz offset) |
| Non-harmonic Wave (Option H04 Ultra Low Phase Noise) | • 100kHz ≤ f ≤ 250MHz: < -58dBc • 250MHz < f ≤ 3.2GHz: < -80dBc • 3.2GHz ＜ f ≤ 10GHz: < -70dBc • 10GHz ＜ f ≤ 20GHz: < -64dBc • 20GHz ＜ f ≤ 40GHz: < -58dBc • 40GHz ＜ f ≤ 67GHz: < -52dBc (At 0dBm, beyond 3kHz offset) |
| SSB Phase Noise (Carrier 1GHz, +10dBm or Max. Output Power) | Standard: • -101 dBc/Hz @ 100Hz offset • -121 dBc/Hz @ 1kHz offset • -130 dBc/Hz @ 10kHz offset • -130 dBc/Hz @ 100kHz offset Option H04: • -62 dBc/Hz @ 1Hz offset • -91 dBc/Hz @ 10Hz offset • -105 dBc/Hz @ 100Hz offset • -123 dBc/Hz @ 1kHz offset • -138 dBc/Hz @ 10kHz offset • -138 dBc/Hz @ 100kHz offset |
| RF Output Port | • 1465A/B/C: N (female), impedance 50Ω • 1465D: 3.5mm (male), N (female) (option 91), impedance 50Ω • 1465F: 2.4mm (male), impedance 50Ω • 1465H/L: 1.85mm (male), impedance 50Ω |
| Power Consumption | < 350W |
| Dimension (max.) | • 426 (W) × 177 (H) × 460 (D) mm (excluding the handle) • 510 (W) × 190 (H) × 534 (D) mm (including the handle) |
| Weight | < 28kg (the weight varies with the model and option configuration) |
| Power Supply | 100-120VAC, 50-60Hz; or 200-240VAC, 50-60Hz (self-adaptive) |
(Note: see more detail information in the ‘Resource’ – ‘Datasheet’) |
Main Machine
| Module No. | Item | Description |
| 1465C | Signal Generator | 100 kHz to 10 GHz |
| 1465D | Signal Generator | 100 kHz to 20 GHz |
| 1465F | Signal Generator | 100 kHz to 40 GHz |
| 1465H | Signal Generator | 100 kHz to 50 GHz |
| 1465L | Signal Generator | 100 kHz to 67 GHz |
Hardware Options
| Module No. | Item | Description |
| 1465-H01A | 115dB Programmable step attenuator | To expand output power dynamic range, for model 1465C/D/F |
| 1465-H01B | 90dB Programmable step attenuator | To expand output power dynamic range, for model 1465H/L |
| 1465-H02A | Analog modulation | Additional analog modulation, including AM, FM, ΦM, and low-frequency output |
| 1465-H02B | Pulse modulation | Additional pulse modulation, with the minimum pulse width of 100ns |
| 1465-H02C | Narrow pulse modulation | Additional pulse modulation, with the minimum pulse width of 20ns |
| 1465-H03 | Analog sweep | Additional analog sweep (slope sweep) |
| 1465-H04 | Ultra low phase noise | To reduce phase noise, 10GHz@10kHz: -120dBc/Hz |
| 1465-H05 | High power output | To increase the maximum output power |
| 1465-H06 | Enhanced high power output | To increase the maximum output power of 10MHz-20GHz substantially |
| 1465-H80 | S87230 USB power probe | For power measurement and calibration (9kHz-6GHz) |
| 1465-H81 | S87231 USB power probe | For power measurement and calibration (10MHz-18GHz) |
| 1465-H82 | S87232 USB power probe | For power measurement and calibration (50MHz-26.5GHz) |
| 1465-H83 | S87233 USB power probe | For power measurement and calibration (50MHz-40GHz) |
| 1465-H90 | Electromagnetic compatibility | As specified in GJB-151A (touch screen disabled) |
| 1465-H91 | Type-N RF output connector | To change RF output port to N (female) |
| 1465-H92 | Back panel RF output | To move RF output port to rear panel |
| 1465-H93 | Front handle kit | Front panel mounting handle |
| 1465-H94 | Machine frame | Kit for installing instrument on the cabinet |
| 1465-H95 | Calibration certificate | Instrument is entrusted to metrology service |
| 1465-H99 | Aluminum alloy transport case | High-strength lightweight aluminum alloy transport case with handle and universal roller for easy transportation |
Software Options
| Module No. | Item | Description |
| 1465-S10 | Complex pulse sequence | Pulse generation mode expansion, support double pulse, multi-pulse, re-frequency staggered, re-frequency jitter, re-frequency slip and other complex pulse sequence generation (need option H02B/C) |
