SCK0TCL18-N mechanical calibration kit providing full open, short and load reflection standards for accurate measurements.
Mechanical Calibration Kit, 18GHz, Type-N, OSL
Key Features
DC to 18GHz frequency coverage
Type-N male or female connector configuration
50 ohm impedance
Application
Site Master
Cable and Antenna Analyzer
Vector Network Analyzer (VNA)
Unit Price: $1,248 (1-5pcs)
NOTICE: Online purchases are temporarily closed. Sorry for the inconvenience.
Detailed
Technical Specifications
| Model | Name | Frequency | Specifications | List |
|---|---|---|---|---|
| SCK0TCL18-N(M) | Type-N calibration kit
T Type |
DC – 18 GHz | Open: ± 1.5° Short: ± 1.0° Load: VSWR < 1.055 |
N (Male) T type calibration kit |
| SCK0TCL18-N(F) | N (Female) T type calibration kit |
Operation Video
How to Place an Order ?
Common Q&A
-
Q: Can I use it in Keysight VNA?
A: Yes, you can, insert the U Disk which we provided to Keysight VNA, import the database, then you can use it successfully.
-
Q: Can I use it to R&S, Anritsu or other brand VNA?
A: Yes, you can. We will provide you a database, you just need to input the data to your VNA at the first time, then can use it freely in future.
-
Q: Can I use it in my Sitemaster or Cable and Antenna Testers?
A: Yes, you can. We will provide you a database, you just need to input the data to your VNA at the first time, then can use it freely in future.
-
Q: What is the warranty time?
A: We guarantee at least 500 times, In case there is quality issue, please contact with us for free repair within one year.
-
Q: Who will afford shipping cost for return?
A: Shipping from your side to our factory need to pay by yourself, we will pay shipping cost when shipping back.
-
Q: Return Policy
A: If there is no quality problem, we do not accept returns and refunds.
-
Q: Refund Policy
A: If the return is caused by the product quality or the mistake from us, you will guaranteed to get the refund by paypal.
